BCR8CM-12LB#BH0 - Renesas Electronics

BCR8CM-12LB#BH0 Details

• Manufacturer Part Number:

  BCR8CM-12LB#BH0

• Brand Name:

  Renesas

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  TO-220ABA

• Pin Count:

  4

• Manufacturer Package Code:

  PRSS0004AT

• ECCN Code:

  EAR99

• Date Of Intro:

  2018-06-28

• Manufacturer:

  Renesas Electronics Corporation

• YTEOL:

  0

• Case Connection:

  MAIN TERMINAL 2

• Configuration:

  SINGLE

• Critical Rate of Rise of Commutation Voltage-Min:

  1 V/us

• DC Gate Trigger Current-Max:

  30 mA

• DC Gate Trigger Voltage-Max:

  1.5 V

• JEDEC-95 Code:

  TO-220AB

• JESD-30 Code:

  R-PSFM-T3

• Number of Elements:

  1

• Number of Terminals:

  3

• On-State Voltage-Max:

  1.5 V

• Operating Temperature-Max:

  150 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  FLANGE MOUNT

• Packing Method:

  TUBE

• RMS On-state Current-Max:

  8 A

• Repetitive Peak Off-state Leakage Current-Max:

  2000 µA

• Repetitive Peak Off-state Voltage:

  600 V

• Surface Mount:

  NO

• Terminal Form:

  THROUGH-HOLE

• Terminal Position:

  SINGLE

• Trigger Device Type:

  TRIAC
