BD10IC0MEFJ-ME2 - ROHM Semiconductor

BD10IC0MEFJ-ME2 Details

• Manufacturer Part Number:

  BD10IC0MEFJ-ME2

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Not Recommended

• Package Description:

  HTSOP-8

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Manufacturer:

  ROHM Semiconductor

• YTEOL:

  3

• Adjustability:

  FIXED

• Dropout Voltage1-Max:

  0.9 V

• Dropout Voltage1-Nom:

  0.4 V

• Input Voltage Absolute-Max:

  7 V

• Input Voltage-Max:

  5.5 V

• Input Voltage-Min:

  2.4 V

• JESD-30 Code:

  R-PDSO-G8

• Length:

  4.9 mm

• Line Regulation-Max:

  0.5%

• Load Regulation-Max:

  0.75%

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  8

• Operating Temperature TJ-Max:

  150 °C

• Operating Temperature-Max:

  105 °C

• Operating Temperature-Min:

  -40 °C

• Output Current1-Max:

  1 A

• Output Voltage1-Max:

  1.03 V

• Output Voltage1-Min:

  0.97 V

• Output Voltage1-Nom:

  1 V

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  HVSOP

• Package Equivalence Code:

  TSOP8,.25

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE, HEAT SINK/SLUG, VERY THIN PROFILE

• Packing Method:

  TR, EMBOSSED

• Peak Reflow Temperature (Cel):

  NOT SPECIFIED

• Qualification Status:

  Not Qualified

• Regulator Type:

  FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR

• Screening Level:

  AEC-Q100

• Seated Height-Max:

  1 mm

• Surface Mount:

  YES

• Terminal Form:

  GULL WING

• Terminal Pitch:

  1.27 mm

• Terminal Position:

  DUAL

• Time@Peak Reflow Temperature-Max (s):

  NOT SPECIFIED

• Voltage Tolerance-Max:

  3%

• Width:

  3.9 mm
