BD6510F-E2 - ROHM Semiconductor

Description: ROHM BD6510F-E2, Quad USB Power Switch High Side, 100mΩ, 8-Pin SOP

Download BD6510F-E2 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
BD6510F-E2 - ROHM Semiconductor PCB footprint - Small Outline Packages - Small Outline Packages - SOP__8
click to zoom

BD6510F-E2 Details

  • Manufacturer Part Number:

    BD6510F-E2

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Obsolete

  • Country Of Origin:

    Philippines

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.01

  • Manufacturer:

    ROHM Semiconductor

  • YTEOL:

    0

  • Driver Number of Bits:

    2

  • JESD-30 Code:

    R-PDSO-G8

  • JESD-609 Code:

    e3

  • Number of Terminals:

    8

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -25 °C

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    SOP

  • Package Equivalence Code:

    SOP8,.25

  • Package Shape:

    RECTANGULAR

  • Package Style:

    SMALL OUTLINE

  • Qualification Status:

    Not Qualified

  • Supply Voltage-Nom:

    5 V

  • Surface Mount:

    YES

  • Technology:

    MOS

  • Temperature Grade:

    OTHER

  • Terminal Form:

    GULL WING

  • Terminal Pitch:

    1.27 mm

  • Terminal Position:

    DUAL

BD6510F-E2 Frequently Asked Questions (FAQs)

  • The recommended operating voltage range for the BD6510F-E2 is 2.5V to 5.5V, although it can operate up to 6.5V with reduced performance.
  • To ensure stable operation in high-temperature environments, it's essential to follow proper thermal design guidelines, such as providing adequate heat sinking, using a thermal interface material, and keeping the junction temperature (Tj) below 125°C.
  • The maximum output current capability of the BD6510F-E2 is 1A per channel, although it's recommended to limit the output current to 500mA per channel for optimal performance and reliability.
  • To configure the BD6510F-E2 for low-power mode operation, you can use the EN (enable) pin to shut down the device when not in use, or use the VSEL (voltage select) pin to select a lower output voltage, which reduces power consumption.
  • The VSEL pin on the BD6510F-E2 allows you to select between two output voltage levels: 3.3V or 5V. This pin can be connected to VCC, GND, or a external voltage source to configure the output voltage.
