A recommended PCB layout for optimal thermal performance would be to have a large copper area on the bottom layer connected to the thermal pad of the BD9007F-E2, and to use thermal vias to dissipate heat to the top layer. Additionally, keeping the PCB layers as thin as possible and using a thermal interface material can also help to improve thermal performance.
To ensure stable operation with a high-ESR output capacitor, it is recommended to add a small ceramic capacitor (e.g. 10nF) in parallel with the output capacitor to improve the overall ESR. Additionally, the output capacitor should be placed as close to the BD9007F-E2 as possible to minimize parasitic inductance.
The maximum allowed voltage on the EN pin is 6V. Exceeding this voltage may cause damage to the internal circuitry of the BD9007F-E2.
The BD9007F-E2 is rated for operation up to 105°C, but it is recommended to derate the output current and input voltage at high temperatures to ensure reliable operation. Additionally, the PCB should be designed to minimize thermal resistance and ensure good airflow to prevent overheating.
To troubleshoot oscillations or instability issues with the BD9007F-E2, check the PCB layout for any signs of parasitic inductance or capacitance, and ensure that the output capacitor is properly decoupled. Additionally, verify that the input voltage is within the recommended range and that the output current is within the specified limits.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
BD9007F-E2 Overview
Use the download button to access the BD9007F-E2 schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like BD900,
or try a keyword search, such as Switching Regulator or Controllers
