ROHM recommends a thermal pad on the bottom of the package, connected to a large copper area on the PCB to dissipate heat efficiently. A minimum of 2oz copper thickness is recommended, and the thermal pad should be connected to a ground plane or a dedicated heat sink.
To ensure stable operation with a high-impedance output load, ROHM recommends adding a 10nF to 100nF capacitor in parallel with the output load to reduce oscillation and improve stability.
The maximum allowed voltage on the EN pin is 6V, exceeding which may cause damage to the device. It's recommended to use a voltage limiter or a resistor divider to ensure the EN pin voltage remains within the specified range.
While the BD9P255EFV-CE2 is rated for operation up to 125°C, ROHM recommends derating the output current and voltage to ensure reliable operation in high-temperature environments. Consult the datasheet and ROHM's application notes for specific guidance.
To troubleshoot output voltage instability or oscillation issues, check the PCB layout for proper thermal design, ensure the input voltage is within the specified range, and verify the output capacitor value and ESR are within the recommended range. Also, check for any noise or ripple on the input voltage and ensure the device is not overheating.
Trust Checks
This model has been built in collaboration with the manufacturer.
Manufacturer Collaborated
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
BD9P255EFV-CE2 Overview
Use the download button to access the BD9P255EFV-CE2 schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like BD9P2,
or try a keyword search, such as Switching Regulator or Controllers
