BDCA-10-25+ - Mini-Circuits

Description: RF Directional Coupler Cellular, PCN, PCS 800MHz ~ 2.5GHz 10.1 ± 2dB 50W 10-SMD, Flat Leads

Download BDCA-10-25+ Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
BDCA-10-25+ - Mini-Circuits PCB footprint - Other - Other - BDCA-10-25+-3
click to zoom
3D Models
BDCA-10-25+ - Mini-Circuits  - 3D model - Other - BDCA-10-25+-3
click to zoom

BDCA-10-25+ Details

  • Manufacturer Part Number:

    BDCA-10-25+

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • ECCN Code:

    EAR99

  • Manufacturer:

    Mini-Circuits

  • YTEOL:

    6.77

  • Characteristic Impedance:

    50 Ω

  • Construction:

    COMPONENT

  • Input Power-Max (CW):

    43.8 dBm

  • Insertion Loss-Max:

    1.5 dB

  • JESD-609 Code:

    e3

  • Operating Frequency-Max:

    2500 MHz

  • Operating Frequency-Min:

    800 MHz

  • Operating Temperature-Max:

    100 °C

  • Operating Temperature-Min:

    -55 °C

  • RF/Microwave Device Type:

    BI-DIRECTIONAL COUPLER

  • Terminal Finish:

    TIN OVER NICKEL

  • VSWR-Max:

    1.05
