BDCN-15-25+ - Mini-Circuits

Description: Signal Conditioning BI-DIR COUP / SURF MT / RoHS

Download BDCN-15-25+ Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
BDCN-15-25+ - Mini-Circuits PCB footprint - Other - Other - FV1206-1-2021
click to zoom
3D Models
BDCN-15-25+ - Mini-Circuits  - 3D model - Other - FV1206-1-2021
click to zoom

BDCN-15-25+ Details

  • Manufacturer Part Number:

    BDCN-15-25+

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Package Description:

    CASE FV1206-1, 6 PIN

  • ECCN Code:

    EAR99

  • Manufacturer:

    Mini-Circuits

  • YTEOL:

    7

  • Characteristic Impedance:

    50 Ω

  • Construction:

    COMPONENT

  • Input Power-Max (CW):

    42.04 dBm

  • Insertion Loss-Max:

    1 dB

  • JESD-609 Code:

    e3

  • Operating Frequency-Max:

    2525 MHz

  • Operating Frequency-Min:

    824 MHz

  • Operating Temperature-Max:

    100 °C

  • Operating Temperature-Min:

    -55 °C

  • RF/Microwave Device Type:

    BI-DIRECTIONAL COUPLER

  • Terminal Finish:

    TIN OVER NICKEL

  • VSWR-Max:

    1.2

BDCN-15-25+ Frequently Asked Questions (FAQs)

  • Mini-Circuits recommends a footprint with a minimum of 50 mils (1.27 mm) of clearance around the device, and a PCB layout that minimizes signal trace lengths and uses 50-ohm impedance-controlled lines to ensure optimal performance.
  • The BDCN-15-25+ requires a bias voltage of +15V to +25V, and a bias current of 100 mA to 200 mA. Ensure the bias circuit is designed to provide a stable voltage and current, and that the device is properly terminated to prevent oscillations.
  • The BDCN-15-25+ can handle up to 1W of input power, but it's recommended to derate the power handling to 0.5W to ensure reliable operation and prevent overheating.
  • Common issues can be caused by improper biasing, poor PCB layout, or incorrect termination. Check the bias circuit, PCB layout, and termination networks, and ensure that the device is properly matched to the system impedance.
  • The BDCN-15-25+ is a commercial-grade device and may not meet the requirements for high-reliability or space applications. Mini-Circuits offers other devices that are specifically designed for these applications, such as the BDCN-15-25+/HS or BDCN-15-25+/SP.
