BE12-4A85-M - STANDEXMEDER

BE12-4A85-M Details

• Manufacturer Part Number:

  BE12-4A85-M

• Part Life Cycle Code:

  Transferred

• Package Description:

  ROHS COMPLIANT

• Country Of Origin:

  Germany

• ECCN Code:

  EAR99

• HTS Code:

  8536.49.00.50

• Manufacturer:

  Standex-Meder Electronics

• YTEOL:

  8.7

• Body Breadth:

  17.3 mm

• Body Height:

  10 mm

• Body Length or Diameter:

  32.4 mm

• Coil Current(DC)-Max:

  0.046 A

• Coil Operate Voltage(DC):

  8.4 V

• Coil Power:

  554 mW

• Coil Release Voltage(DC):

  0.75 V

• Coil Resistance:

  286 Ω

• Coil Voltage(DC)-Max:

  12 V

• Coil/Input Supply Type:

  DC

• Contact (AC) Max Rating R Load:

  1A@1000VAC

• Contact Current(AC)-Max:

  1 A

• Contact Current(DC)-Max:

  1 A

• Contact (DC) Max Rating R Load:

  1A@1000VDC

• Contact Voltage(AC)-Max:

  1000 V

• Contact Voltage(DC)-Max:

  1000 V

• Contact/Output Supply Type:

  AC/DC

• JESD-609 Code:

  e3

• Mounting Feature:

  THROUGH HOLE-STRAIGHT

• Operate Time:

  1.1 ms

• Operating Temperature-Max:

  70 °C

• Operating Temperature-Min:

  -20 °C

• Packing Method:

  TUBE

• Physical Dimension:

  32.4mm x 17.3mm x 10mm

• Relay Action:

  MOMENTARY

• Relay Function:

  4PST

• Relay Type:

  DRY REED RELAY

• Release Time:

  0.1 ms

• Sealing:

  WATER PROOF

• Surface Mount:

  NO

• Terminal Finish:

  Tin (Sn)

• Termination Type:

  SOLDER
