BE24-4A73-M - Meder

BE24-4A73-M Details

• Manufacturer Part Number:

  BE24-4A73-M

• Part Life Cycle Code:

  Obsolete

• ECCN Code:

  EAR99

• HTS Code:

  8536.49.00.50

• Manufacturer:

  Standex-Meder Electronics

• YTEOL:

  0

• Body Breadth:

  17.1 mm

• Body Height:

  10 mm

• Body Length or Diameter:

  32.4 mm

• Coil Current(DC)-Max:

  0.024 A

• Coil Operate Voltage(DC):

  16.8 V

• Coil Power:

  585 mW

• Coil Release Voltage(DC):

  1.5 V

• Coil Resistance:

  1083 Ω

• Coil Voltage(DC)-Max:

  24 V

• Coil/Input Supply Type:

  DC

• Contact (AC) Max Rating R Load:

  1A@200VAC

• Contact Current(AC)-Max:

  1 A

• Contact Current(DC)-Max:

  1 A

• Contact (DC) Max Rating R Load:

  1A@200VDC

• Contact Voltage(AC)-Max:

  200 V

• Contact Voltage(DC)-Max:

  200 V

• Contact/Output Supply Type:

  AC/DC

• Mounting Feature:

  THROUGH HOLE-STRAIGHT MOUNT

• Operate Time:

  0.5 ms

• Operating Temperature-Max:

  70 °C

• Operating Temperature-Min:

  -20 °C

• Physical Dimension:

  32.4mm x 17.1mm x 10mm

• Relay Action:

  MOMENTARY

• Relay Function:

  4PST

• Relay Type:

  DRY REED RELAY

• Release Time:

  0.1 ms

• Sealing:

  WATER PROOF

• Surface Mount:

  NO

• Termination Type:

  SOLDER
