BH2226FV-E2 - ROHM Semiconductor

BH2226FV-E2 Details

• Manufacturer Part Number:

  BH2226FV-E2

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Part Package Code:

  SOIC

• Package Description:

  SSOP-16

• Pin Count:

  16

• Country Of Origin:

  Philippines

• HTS Code:

  8542.39.00.40

• Manufacturer:

  ROHM Semiconductor

• YTEOL:

  6.2

• Analog Output Voltage-Max:

  5.5 V

• Analog Output Voltage-Min:

  2.6 V

• Converter Type:

  D/A CONVERTER

• Input Bit Code:

  BINARY

• Input Format:

  SERIAL

• JESD-30 Code:

  R-PDSO-G16

• Length:

  5 mm

• Linearity Error-Max (EL):

  0.5859%

• Number of Bits:

  8

• Number of Functions:

  1

• Number of Terminals:

  16

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -20 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  SSOP

• Package Equivalence Code:

  TSSOP16,.25

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE, SHRINK PITCH

• Peak Reflow Temperature (Cel):

  NOT SPECIFIED

• Qualification Status:

  Not Qualified

• Seated Height-Max:

  1.25 mm

• Settling Time-Max:

  100 µs

• Settling Time-Nom (tstl):

  100 µs

• Supply Current-Max:

  2.5 mA

• Supply Voltage-Nom:

  3 V

• Surface Mount:

  YES

• Temperature Grade:

  OTHER

• Terminal Form:

  GULL WING

• Terminal Pitch:

  0.65 mm

• Terminal Position:

  DUAL

• Time@Peak Reflow Temperature-Max (s):

  NOT SPECIFIED

• Width:

  4.4 mm
