ROHM recommends a thermal pad on the bottom of the package, connected to a large copper area on the PCB to dissipate heat efficiently. A minimum of 2oz copper thickness is recommended, and the thermal pad should be connected to a ground plane to reduce thermal resistance.
To ensure reliable operation in high-temperature environments, it's essential to follow proper thermal design and layout guidelines. Additionally, consider using a heat sink or thermal interface material to reduce the junction temperature. ROHM also recommends derating the output current and voltage according to the temperature derating curve provided in the datasheet.
ROHM recommends using a low-ESR ceramic capacitor (X5R or X7R dielectric) with a value of 4.7uF to 10uF for the input capacitor. This helps to reduce input voltage ripple and ensure stable operation.
To troubleshoot issues with the BH76360FV-E2, start by checking the input voltage, output voltage, and current. Verify that the input capacitor is properly connected and of the recommended type and value. Check for any signs of overheating, such as excessive temperature rise or thermal shutdown. Consult the datasheet and application notes for guidance on troubleshooting and fault detection.
Yes, the BH76360FV-E2 can be used in a parallel configuration to increase output current. However, it's essential to ensure that the devices are properly synchronized and matched to prevent current imbalance and oscillation. ROHM recommends using a master-slave configuration with a single clock signal and a shared feedback network to ensure stable operation.
Trust Checks
This model has been built in collaboration with the manufacturer.
Manufacturer Collaborated
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
BH76360FV-E2 Overview
Use the download button to access the BH76360FV-E2 schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like BH763,
or try a keyword search, such as Multiplexers or Switches
