BLUENRG-332AC footprint, schematic symbol and 3D model by STMicroelectronics

Symbol

click to zoom

PCB Footprints

BLUENRG-332AC - STMicroelectronics PCB footprint - Quad Flat No-Lead - Quad Flat No-Lead - QFN32 (5x5x0.9, pitch 0.5 mm) package information-

click to zoom

3D Models

BLUENRG-332AC - STMicroelectronics - 3D model - Quad Flat No-Lead - QFN32 (5x5x0.9, pitch 0.5 mm) package information-

click to zoom

Datasheet Download Datasheet
Stock & Prices Price & Stock for BLUENRG-332AC
Part Number BLUENRG-332AC
Manufacturer STMicroelectronics
Pin Count 33
Part Category Integrated Circuit
Package Category Quad Flat No-Lead
Footprint Name Quad Flat No-Lead - QFN32 (5x5x0.9, pitch 0.5 mm) package information-
Released Date Aug 26, 2022
Last Modified Date Jan 8, 2026 2:31 PM UTC
Pinout / Pin List Click Here (Member Only)

BLUENRG-332AC Details

Manufacturer Part Number:
BLUENRG-332AC
Brand Name:
STMicroelectronics
Rohs Code:
Yes
Part Life Cycle Code:
Active
Package Description:
QFN-32
Country Of Origin:
Thailand
ECCN Code:
5A992.C
HTS Code:
8542.31.00.30
Factory Lead Time:
12 Weeks
Manufacturer:
STMicroelectronics
YTEOL:
8
JESD-30 Code:
S-XQCC-N32
Length:
5 mm
Number of Terminals:
32
Operating Temperature-Max:
85 °C
Operating Temperature-Min:
-40 °C
Package Body Material:
UNSPECIFIED
Package Code:
HVQCCN
Package Equivalence Code:
LCC32,.2SQ,20
Package Shape:
SQUARE
Package Style:
CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE
Seated Height-Max:
1 mm
Supply Voltage-Max:
3.6 V
Supply Voltage-Min:
1.7 V
Supply Voltage-Nom:
1.8 V
Surface Mount:
YES
Technology:
CMOS
Terminal Form:
NO LEAD
Terminal Pitch:
0.5 mm
Terminal Position:
QUAD
Width:
5 mm
uPs/uCs/Peripheral ICs Type:
RFSoC

BLUENRG-332AC Frequently Asked Questions (FAQs)

The maximum transmit power of the BLUENRG-332AC is +8 dBm.
To configure the BLUENRG-332AC for Bluetooth 5.0, you need to set the device to use the 2M PHY and enable the LE 2M feature bit in the HCI commands. Additionally, you need to ensure that your firmware is compatible with Bluetooth 5.0.
Yes, the BLUENRG-332AC has an internal antenna, but you can also use an external antenna by connecting it to the RF pin and disabling the internal antenna through the API.
To implement coexistence with other 2.4 GHz devices, you need to use the Adaptive Frequency Hopping (AFH) feature of the BLUENRG-332AC, which allows the device to adapt its frequency hopping sequence to avoid interference from other devices.
The power consumption of the BLUENRG-332AC in sleep mode is typically around 1.5 μA, but this can vary depending on the specific configuration and usage scenario.
