BM2P015-Z - ROHM Semiconductor

BM2P015-Z Details

• Manufacturer Part Number:

  BM2P015-Z

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  DIP-7

• Country Of Origin:

  Philippines

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Date Of Intro:

  2019-10-23

• Manufacturer:

  ROHM Semiconductor

• YTEOL:

  6.2

• Analog IC - Other Type:

  SWITCHING REGULATOR

• Control Mode:

  CURRENT-MODE

• Control Technique:

  PULSE WIDTH MODULATION

• Input Voltage-Max:

  26 V

• Input Voltage-Min:

  8.9 V

• Input Voltage-Nom:

  15 V

• JESD-30 Code:

  R-PDIP-T7

• Length:

  9.27 mm

• Number of Functions:

  1

• Number of Terminals:

  7

• Operating Temperature-Max:

  105 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  10.4 A

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  DIP

• Package Equivalence Code:

  DIP7/8,.3

• Package Shape:

  RECTANGULAR

• Package Style:

  IN-LINE

• Peak Reflow Temperature (Cel):

  NOT SPECIFIED

• Seated Height-Max:

  5.33 mm

• Supply Voltage-Nom (Vsup):

  15 V

• Surface Mount:

  NO

• Switching Frequency-Max:

  70 kHz

• Temperature Grade:

  INDUSTRIAL

• Terminal Form:

  THROUGH-HOLE

• Terminal Pitch:

  2.54 mm

• Terminal Position:

  DUAL

• Time@Peak Reflow Temperature-Max (s):

  NOT SPECIFIED

• Width:

  7.62 mm
