BP2C+ - Mini-Circuits

Description: Signal Conditioning 2 Ways MMIC DC Pass Power Splitter, 810 - 960 MHz, 50 ohms

Download BP2C+ Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
BP2C+ - Mini-Circuits PCB footprint - Small Outline Packages - Small Outline Packages - SOIC8
click to zoom

BP2C+ Details

  • Manufacturer Part Number:

    BP2C+

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Obsolete

  • ECCN Code:

    EAR99

  • Manufacturer:

    Mini-Circuits

  • YTEOL:

    0

  • Characteristic Impedance:

    50 Ω

  • Construction:

    COMPONENT

  • Input Power-Max (CW):

    31.76 dBm

  • Insertion Loss-Max:

    0.9 dB

  • Isolation-Min:

    17 dB

  • JESD-609 Code:

    e2

  • Mounting Feature:

    SURFACE MOUNT

  • Number of Terminals:

    8

  • Operating Frequency-Max:

    960 MHz

  • Operating Frequency-Min:

    810 MHz

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -40 °C

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Equivalence Code:

    SOP8,.25

  • RF/Microwave Device Type:

    SPLITTER AND COMBINER

  • Surface Mount:

    YES

  • Terminal Finish:

    Tin/Silver/Nickel (Sn/Ag/Ni)

  • VSWR-Max:

    1.15

BP2C+ Frequently Asked Questions (FAQs)

  • A 4-layer PCB with a solid ground plane and a separate power plane is recommended. Keep the input and output traces as short as possible and use 50-ohm microstrip lines.
  • Apply a voltage of 12-15V to the VCC pin and a voltage of -5V to -12V to the VEE pin. Ensure the voltage supply is well-regulated and decoupled with capacitors.
  • The BP2C+ can handle up to +20 dBm of input power. Exceeding this may cause compression or damage to the device.
  • Use the recommended component values for the input and output matching networks, and adjust the values based on the specific frequency range of interest. Simulation tools like ADS or AWR can be used to optimize the design.
  • The typical noise figure of the BP2C+ is around 3.5 dB, but this can vary depending on the specific application and operating conditions.
