BPA05SBR - LITTELFUSE

BPA05SBR Details

• Manufacturer Part Number:

  BPA05SBR

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  ROHS COMPLIANT

• Country Of Origin:

  Mainland China

• ECCN Code:

  EAR99

• HTS Code:

  8536.50.90.65

• Manufacturer:

  Littelfuse Inc

• YTEOL:

  7

• Actuator Length:

  0.083 inch

• Actuator Material:

  POLYAMIDE

• Actuator Type:

  SLIDE TYPE

• Additional Feature:

  ROHS COMPLIANT; T/R PACKAGING

• Body Breadth:

  8.15 mm

• Body Height:

  6 mm

• Body Length or Diameter:

  14.6 mm

• Center Contact Material:

  BERYLLIUM COPPER

• Center Contact Plating:

  GOLD OVER NICKEL

• Contact Current(DC)-Max:

  0.1 A

• Contact (DC) Max Rating R Load:

  .1A@5VDC

• Contact Resistance:

  0.05 mΩ

• Contact Voltage(DC)-Max:

  5 V

• Dielectric Withstand Volts:

  300VAC V

• Electrical Life:

  1000 Cycle(s)

• End Contact Material:

  BERYLLIUM COPPER

• End Contact Plating:

  GOLD OVER NICKEL

• Housing Material:

  POLYPHENYLENE SULPHIDE

• Insulation Resistance:

  100000000 Ω

• JESD-609 Code:

  e4

• Mounting Feature:

  SURFACE MOUNT-STRAIGHT

• Number of Positions:

  5

• Number of Switch Sections:

  1

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -20 °C

• Packing Method:

  TAPE AND REEL

• Surface Mount:

  NO

• Switch Action:

  LATCHED

• Switch Function:

  SPST

• Switch Type:

  SLIDE DIP SWITCH

• Terminal Finish:

  GOLD OVER NICKEL

• Terminal Material:

  BRASS

• Termination Type:

  SOLDER
