BR25H080F-2CE2 - ROHM Semiconductor

BR25H080F-2CE2 Details

• Manufacturer Part Number:

  BR25H080F-2CE2

• Rohs Code:

  Yes

• Part Life Cycle Code:

  End Of Life

• Country Of Origin:

  Philippines

• ECCN Code:

  EAR99

• HTS Code:

  8542.32.00.51

• Manufacturer:

  ROHM Semiconductor

• YTEOL:

  3

• Additional Feature:

  ALSO OPERATES AT 2.5V WITH 5MHZ AND SEATED HT-CALCULATED

• Clock Frequency-Max (fCLK):

  10 MHz

• Data Retention Time-Min:

  100

• Endurance:

  1000000 Write/Erase Cycles

• JESD-30 Code:

  R-PDSO-G8

• Length:

  5 mm

• Memory Density:

  8192 bit

• Memory IC Type:

  EEPROM

• Memory Width:

  8

• Number of Functions:

  1

• Number of Terminals:

  8

• Number of Words:

  1024 words

• Number of Words Code:

  1000

• Operating Mode:

  SYNCHRONOUS

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Organization:

  1KX8

• Output Characteristics:

  3-STATE

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  SOP

• Package Equivalence Code:

  SOP8,.25

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Parallel/Serial:

  SERIAL

• Qualification Status:

  Not Qualified

• Screening Level:

  AEC-Q100

• Seated Height-Max:

  1.71 mm

• Serial Bus Type:

  SPI

• Supply Current-Max:

  0.004 mA

• Supply Voltage-Max (Vsup):

  5.5 V

• Supply Voltage-Min (Vsup):

  4.5 V

• Supply Voltage-Nom (Vsup):

  5 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Temperature Grade:

  AUTOMOTIVE

• Terminal Form:

  GULL WING

• Terminal Pitch:

  1.27 mm

• Terminal Position:

  DUAL

• Width:

  4.4 mm

• Write Cycle Time-Max (tWC):

  4 ms

• Write Protection:

  HARDWARE/SOFTWARE
