BRNS6 - Cosel

BRNS6 Details

• Manufacturer Part Number:

  BRNS6

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Not Recommended

• Package Description:

  PACKAGE-17

• ECCN Code:

  EAR99

• Manufacturer:

  Cosel USA Inc

• YTEOL:

  3

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Approvals:

  UL, C-UL, EN

• Efficiency (Main Output):

  86%

• Input Voltage-Max:

  14.4 V

• Input Voltage-Min:

  3 V

• JESD-30 Code:

  S-XXMA-N17

• Length:

  12.2 mm

• Line Regulation-Max:

  0.5%

• Load Regulation-Max:

  0.5%

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  17

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  6 A

• Output Voltage-Max:

  5.5 V

• Output Voltage-Min:

  0.6 V

• Package Body Material:

  UNSPECIFIED

• Package Code:

  XMA

• Package Shape:

  SQUARE

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Peak Reflow Temperature (Cel):

  NOT SPECIFIED

• Protections:

  OVER CURRENT

• Ripple Voltage (Main Out):

  0.017675 Vrms

• Seated Height-Max:

  7.2 mm

• Surface Mount:

  NO

• Technology:

  HYBRID

• Terminal Form:

  NO LEAD

• Terminal Position:

  UNSPECIFIED

• Time@Peak Reflow Temperature-Max (s):

  NOT SPECIFIED

• Total Power Output-Max:

  33 W

• Trim/Adjustable Output:

  YES

• Warm-up Time:

  0.0045 s

• Width:

  12.2 mm
