BSC155N06NDATMA1 - Infineon

BSC155N06NDATMA1 Details

• Manufacturer Part Number:

  BSC155N06NDATMA1

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  TDSON, SOP-8

• Country Of Origin:

  Mainland China, Malaysia

• ECCN Code:

  EAR99

• Factory Lead Time:

  14 Weeks

• Manufacturer:

  Infineon Technologies AG

• YTEOL:

  5

• Avalanche Energy Rating (Eas):

  40 mJ

• Case Connection:

  DRAIN

• Configuration:

  SEPARATE, 2 ELEMENTS WITH BUILT-IN DIODE

• DS Breakdown Voltage-Min:

  60 V

• Drain Current-Max (ID):

  42 A

• Drain-source On Resistance-Max:

  0.0155 Ω

• FET Technology:

  METAL-OXIDE SEMICONDUCTOR

• Feedback Cap-Max (Crss):

  30 pF

• JESD-30 Code:

  R-PDSO-F8

• JESD-609 Code:

  e3

• Moisture Sensitivity Level:

  1

• Number of Elements:

  2

• Number of Terminals:

  8

• Operating Mode:

  ENHANCEMENT MODE

• Operating Temperature-Max:

  175 °C

• Operating Temperature-Min:

  -55 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Polarity/Channel Type:

  N-CHANNEL

• Power Dissipation-Max (Abs):

  50 W

• Pulsed Drain Current-Max (IDM):

  168 A

• Reference Standard:

  IEC-68-1; IEC-61249-2-21

• Surface Mount:

  YES

• Terminal Finish:

  Tin (Sn)

• Terminal Form:

  FLAT

• Terminal Position:

  DUAL

• Transistor Application:

  SWITCHING

• Transistor Element Material:

  SILICON
