BTB12-12S25D - Bellnix

BTB12-12S25D Details

• Manufacturer Part Number:

  BTB12-12S25D

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Contact Manufacturer

• Package Description:

  ROHS COMPLIANT, METAL, DIP-11

• ECCN Code:

  EAR99

• Manufacturer:

  Bellnix Co Ltd

• Additional Feature:

  OUTPUT VOLTAGE ALSO AVAILABLE IN 15 VOLT, LG-MAX

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Input Voltage-Max:

  18 V

• Input Voltage-Min:

  9 V

• Input Voltage-Nom:

  12 V

• JESD-30 Code:

  R-MDMA-T11

• Length:

  23.7 mm

• Load Regulation-Max:

  0.85%

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  11

• Output Voltage-Max:

  15 V

• Output Voltage-Min:

  11.4 V

• Output Voltage-Nom:

  12 V

• Package Body Material:

  METAL

• Package Code:

  DMA

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Peak Reflow Temperature (Cel):

  NOT SPECIFIED

• Seated Height-Max:

  8.5 mm

• Surface Mount:

  NO

• Technology:

  HYBRID

• Terminal Form:

  THROUGH-HOLE

• Terminal Position:

  DUAL

• Time@Peak Reflow Temperature-Max (s):

  NOT SPECIFIED

• Total Power Output-Max:

  3 W

• Trim/Adjustable Output:

  YES

• Width:

  16.6 mm
