BTB24-600BRG - STMicroelectronics

BTB24-600BRG Details

• Manufacturer Part Number:

  BTB24-600BRG

• Brand Name:

  STMicroelectronics

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Part Package Code:

  TO-220AB

• Pin Count:

  3

• Country Of Origin:

  Mainland China

• ECCN Code:

  EAR99

• HTS Code:

  8541.30.00.80

• Factory Lead Time:

  15 Weeks

• Manufacturer:

  STMicroelectronics

• YTEOL:

  6

• Case Connection:

  MAIN TERMINAL 2

• Configuration:

  SINGLE

• Critical Rate of Rise of Commutation Voltage-Min:

  10 V/us

• Critical Rate of Rise of Off-State Voltage-Min:

  500 V/us

• DC Gate Trigger Current-Max:

  50 mA

• DC Gate Trigger Voltage-Max:

  1.3 V

• Holding Current-Max:

  80 mA

• JEDEC-95 Code:

  TO-220AB

• JESD-30 Code:

  R-PSFM-T3

• JESD-609 Code:

  e3

• Leakage Current-Max:

  3 mA

• Number of Elements:

  1

• Number of Terminals:

  3

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  FLANGE MOUNT

• Qualification Status:

  Not Qualified

• RMS On-state Current-Max:

  25 A

• Reference Standard:

  UL RECOGNIZED

• Repetitive Peak Off-state Voltage:

  600 V

• Surface Mount:

  NO

• Terminal Finish:

  Matte Tin (Sn)

• Terminal Form:

  THROUGH-HOLE

• Terminal Position:

  SINGLE

• Trigger Device Type:

  TRIAC
