- Datasheet Download Datasheet
- Stock & Prices $ Price & Stock for BTS5200-1ENA
- Part Number BTS5200-1ENA
- Manufacturer Infineon
- Pin Count 9
- Part Category Switch
- Package Category Small Outline Packages
- Footprint Name Small Outline Packages - PG-TDSO-8-31
- Released Date Jun 16, 2023
- Last Modified Date Jun 16, 2023 6:25 AM UTC
- Pinout / Pin List Click Here (Member Only)
BTS5200-1ENA Details
-
Manufacturer Part Number:
BTS5200-1ENA
-
Rohs Code:
Yes
-
Part Life Cycle Code:
Active
-
Country Of Origin:
Malaysia
-
ECCN Code:
EAR99
-
HTS Code:
8542.39.00.60
-
Manufacturer:
Infineon Technologies AG
-
YTEOL:
9
-
Interface IC Type:
BUFFER OR INVERTER BASED PERIPHERAL DRIVER
-
Moisture Sensitivity Level:
2A
-
Terminal Finish:
Tin (Sn)
BTS5200-1ENA Frequently Asked Questions (FAQs)
-
Infineon provides a recommended PCB layout in the application note AN215 'Layout Recommendations for BTS5200-1ENA' which includes guidelines for component placement, thermal management, and routing.
-
The sense resistor value depends on the maximum current and voltage of your application. Infineon provides a calculation formula in the datasheet, and also offers a online calculation tool to help with the selection.
-
The maximum junction temperature of the BTS5200-1ENA is 150°C. However, it's recommended to keep the junction temperature below 125°C for reliable operation and to ensure the device's lifetime.
-
Yes, the BTS5200-1ENA is designed to operate in high-temperature environments up to 150°C. However, the device's performance and reliability may be affected at high temperatures, and additional thermal management may be required.
-
Infineon provides a troubleshooting guide in the application note AN216 'Troubleshooting Guide for BTS5200-1ENA' which includes common issues, symptoms, and solutions. Additionally, Infineon's support team can be contacted for further assistance.
Trust Checks
Community Provided
System Verified
Community Approved
BTS5200-1ENA Overview
Use the download button to access the BTS5200-1ENA schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like BTS52,
or try a keyword search, such as Peripheral Drivers
