- Part Number BTS6403UJ
- Manufacturer NXP
- Pin Count 17
- Part Category Integrated Circuit
- Package Category Quad Flat No-Lead
- Footprint Name Quad Flat No-Lead - HVQFN16_1
- Released Date Nov 20, 2024
- Last Modified Date Nov 20, 2024 9:58 AM UTC
- Pinout / Pin List Click Here (Member Only)
BTS6403UJ Details
-
Manufacturer Part Number:
BTS6403UJ
-
Rohs Code:
Yes
-
Part Life Cycle Code:
End Of Life
-
Factory Lead Time:
13 Weeks
-
Manufacturer:
NXP Semiconductors
-
YTEOL:
0
-
RF/Microwave Device Type:
WIDE BAND MEDIUM POWER
-
Terminal Finish:
Nickel/Palladium/Gold (Ni/Pd/Au)
BTS6403UJ Frequently Asked Questions (FAQs)
-
The BTS6403UJ can operate from -40°C to 150°C, but the maximum junction temperature (Tj) should not exceed 150°C.
-
To ensure SOA, follow the guidelines in the datasheet for voltage, current, and power dissipation. Also, consider the thermal resistance, PCB layout, and heat sink design to prevent overheating.
-
Use a multi-layer PCB with a solid ground plane, and place the device near a heat sink or a thermal pad. Ensure good thermal conductivity and minimize thermal resistance. Refer to the NXP application note AN11160 for more details.
-
Choose components with suitable voltage and current ratings, and consider the operating frequency, noise tolerance, and parasitic effects. Refer to the datasheet and application notes for specific recommendations.
-
The BTS6403UJ has built-in ESD protection, but additional external protection may be necessary depending on the application. Follow proper PCB design and handling practices to prevent latch-up and ESD damage.
Trust Checks
Community Provided
System Verified
Community Approved
BTS6403UJ Overview
Use the download button to access the BTS6403UJ schematic symbol, PCB footprint, and 3D model.
