A good PCB layout for the BU9480F-E2 involves keeping the input and output capacitors close to the IC, using a solid ground plane, and minimizing the length of the power traces. Additionally, it's recommended to use a shielded inductor and to keep the switching node (SW pin) away from sensitive analog circuits.
To ensure the stability of the output voltage, it's essential to choose the right output capacitor value and type. A low-ESR capacitor with a value between 10uF to 22uF is recommended. Additionally, the output voltage can be stabilized by adding a capacitor (typically 10nF to 100nF) between the FB pin and GND.
The BU9480F-E2 can operate in an ambient temperature range of -40°C to 105°C. However, the maximum junction temperature (TJ) should not exceed 125°C.
Yes, the BU9480F-E2 is suitable for high-reliability applications. It's built with a robust design and has undergone rigorous testing to ensure its reliability. However, it's essential to follow proper design and manufacturing guidelines to ensure the reliability of the overall system.
The power dissipation of the BU9480F-E2 can be calculated using the following formula: Pd = (Vin x Iq) + (Io x Vo x η), where Pd is the power dissipation, Vin is the input voltage, Iq is the quiescent current, Io is the output current, Vo is the output voltage, and η is the efficiency of the converter.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
BU9480F-E2 Overview
Use the download button to access the BU9480F-E2 schematic symbol and PCB footprint.
To find more CAD model downloads similar to this part, try a partial part number search, like BU948,
or try a keyword search, such as Digital to Analog Converters
