ROHM recommends a thermal pad on the bottom of the package, connected to a large copper area on the PCB to dissipate heat efficiently. A minimum of 2oz copper thickness is recommended.
ROHM recommends derating the voltage and current ratings according to the temperature derating curve provided in the datasheet. Additionally, ensure good thermal design and heat dissipation to prevent overheating.
ROHM recommends a soldering profile with a peak temperature of 260°C, a dwell time of 10-30 seconds, and a cooling rate of 3-5°C/s. Refer to the ROHM soldering guidelines for more information.
Yes, the BV1LA025EFJ-CE2 is AEC-Q101 qualified, making it suitable for automotive and high-reliability applications. However, ensure that you follow the recommended operating conditions and design guidelines to meet the required reliability standards.
ROHM recommends following standard ESD handling procedures, such as using an ESD wrist strap, mat, or workstation, and ensuring that all equipment and tools are properly grounded. The BV1LA025EFJ-CE2 has an ESD rating of 2kV human body model (HBM).
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
BV1LA025EFJ-CE2 Overview
Use the download button to access the BV1LA025EFJ-CE2 schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like BV1LA,
or try a keyword search, such as Peripheral Drivers
