BXA-24529 - JKL Components

BXA-24529 Details

• Manufacturer Part Number:

  BXA-24529

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  PACKAGE-5

• ECCN Code:

  EAR99

• Manufacturer:

  JKL Components Corporation

• YTEOL:

  6

• Analog IC - Other Type:

  DC-AC INVERTER POWER SUPPLY MODULE

• Input Voltage-Max:

  26.4 V

• Input Voltage-Min:

  21.6 V

• Input Voltage-Nom:

  24 V

• JESD-30 Code:

  R-XXMA-P5

• Length:

  44 mm

• Number of Functions:

  1

• Number of Outputs:

  2

• Number of Terminals:

  5

• Operating Temperature-Max:

  50 °C

• Output Current-Max:

  0.0065 A

• Output Voltage-Max:

  1555.649837 V

• Output Voltage-Min:

  1272.804412 V

• Output Voltage-Nom:

  1414.2271 V

• Package Body Material:

  UNSPECIFIED

• Package Code:

  XMA

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Seated Height-Max:

  15 mm

• Surface Mount:

  NO

• Technology:

  HYBRID

• Terminal Form:

  PIN/PEG

• Terminal Position:

  UNSPECIFIED

• Total Power Output-Max:

  18.3849 W

• Trim/Adjustable Output:

  NO

• Width:

  21 mm
