BZA962A,115 - Nexperia

Description: BZA900A-series - Quadruple ESD transient voltage suppressor

Download BZA962A,115 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
BZA962A,115 - Nexperia - PCB symbol
click to zoom
PCB Footprints
BZA962A,115 - Nexperia PCB footprint - SO Transistor Flat Lead - SO Transistor Flat Lead - SOT665
click to zoom
3D Models
BZA962A,115 - Nexperia - 3D model - SO Transistor Flat Lead - SOT665
click to zoom

BZA962A,115 Details

  • Manufacturer Part Number:

    BZA962A,115

  • Brand Name:

    Nexperia

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Part Package Code:

    SOT

  • Package Description:

    ULTRA SMALL, PLASTIC, SMD, 5 PIN

  • Pin Count:

    5

  • Manufacturer Package Code:

    SOT665

  • Country Of Origin:

    Malaysia

  • ECCN Code:

    EAR99

  • HTS Code:

    8541.10.00.50

  • Factory Lead Time:

    8 Weeks

  • Manufacturer:

    Nexperia

  • YTEOL:

    5.98

  • Configuration:

    COMMON ANODE, 4 ELEMENTS, 4 CHANNEL

  • Diode Element Material:

    SILICON

  • Diode Type:

    TRANS VOLTAGE SUPPRESSOR DIODE

  • JESD-30 Code:

    R-PDSO-F5

  • JESD-609 Code:

    e3

  • Moisture Sensitivity Level:

    1

  • Non-rep Peak Rev Power Dis-Max:

    15 W

  • Number of Elements:

    4

  • Number of Terminals:

    5

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Shape:

    RECTANGULAR

  • Package Style:

    SMALL OUTLINE

  • Peak Reflow Temperature (Cel):

    260

  • Polarity:

    UNIDIRECTIONAL

  • Power Dissipation-Max:

    0.335 W

  • Qualification Status:

    Not Qualified

  • Reference Standard:

    IEC-61000-4-2

  • Rep Pk Reverse Voltage-Max:

    4 V

  • Reverse Current-Max:

    0.5 µA

  • Reverse Test Voltage:

    4 V

  • Surface Mount:

    YES

  • Technology:

    AVALANCHE

  • Terminal Finish:

    TIN

  • Terminal Form:

    FLAT

  • Terminal Position:

    DUAL

  • Time@Peak Reflow Temperature-Max (s):

    30

BZA962A,115 Frequently Asked Questions (FAQs)

  • The recommended PCB footprint for BZA962A,115 is a standard SOT23 package with a minimum pad size of 0.8 mm x 0.8 mm and a maximum pad size of 1.2 mm x 1.2 mm, with a non-solder mask defined (NSMD) pad shape.
  • To ensure reliable operation of BZA962A,115 in high-temperature environments, it is recommended to follow proper thermal design and layout guidelines, such as providing adequate heat dissipation paths, using thermal vias, and keeping the device away from heat sources.
  • The maximum allowed voltage on the gate of BZA962A,115 is ±20 V, but it is recommended to limit the gate voltage to ±15 V to ensure reliable operation and prevent damage to the device.
  • Yes, BZA962A,115 can be used in switching applications, but it is essential to ensure that the device is operated within its safe operating area (SOA) and that the switching frequency is limited to avoid overheating and reduce electromagnetic interference (EMI).
  • To protect BZA962A,115 from ESD, it is recommended to follow proper handling and storage procedures, such as using anti-static bags, wrist straps, and mats, and ensuring that the device is properly grounded during assembly and testing.
