C1099-A - COILCRAFT

C1099-A Details

• Manufacturer Part Number:

  C1099-A

• Pbfree Code:

  No

• Part Life Cycle Code:

  Obsolete

• ECCN Code:

  EAR99

• Manufacturer:

  Coilcraft Inc

• YTEOL:

  0

• Additional Feature:

  TURNS RATIO: 1:0.13:0.57, HEIGHT DIMENSION INCLUDES TERMINAL ALSO

• Height:

  8.51 mm

• Input Voltage-Max:

  56 V

• Input Voltage-Min:

  32 V

• Length:

  17.2 mm

• Mounting Feature:

  SURFACE MOUNT

• Number of Primary Winding:

  3

• Number of Secondary Winding:

  1

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Output Voltage 1:

  3.3 V

• Packing Method:

  TAPE & REEL

• Primary Inductance:

  133 µH

• Surface Mount:

  YES

• Transformer Type:

  SMPS TRANSFORMER

• Width:

  14.98 mm
