C11152-01 - Hamamatsu

C11152-01 Details

• Manufacturer Part Number:

  C11152-01

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  PACKAGE-9

• Country Of Origin:

  Japan

• ECCN Code:

  EAR99

• Manufacturer:

  Hamamatsu Photonics

• YTEOL:

  6

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Input Voltage-Max:

  12.5 V

• Input Voltage-Min:

  11.5 V

• Input Voltage-Nom:

  12 V

• JESD-30 Code:

  S-MDMA-T9

• Length:

  41 mm

• Line Regulation-Max:

  0.01%

• Load Regulation-Max:

  0.01%

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  9

• Operating Temperature-Max:

  50 °C

• Output Current-Max:

  0.001 A

• Output Voltage-Max:

  -1500 V

• Package Body Material:

  METAL

• Package Code:

  DMA

• Package Shape:

  SQUARE

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Peak Reflow Temperature (Cel):

  NOT SPECIFIED

• Protections:

  SHORT CIRCUIT, OVER LOAD

• Ripple Voltage (Main Out):

  0.002828 Vrms

• Seated Height-Max:

  10 mm

• Surface Mount:

  NO

• Technology:

  HYBRID

• Terminal Form:

  THROUGH-HOLE

• Terminal Position:

  DUAL

• Time@Peak Reflow Temperature-Max (s):

  NOT SPECIFIED

• Total Power Output-Max:

  1.5 W

• Trim/Adjustable Output:

  YES

• Width:

  41 mm
