C11204-02 - Hamamatsu

C11204-02 Details

• Manufacturer Part Number:

  C11204-02

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  PACKAGE-20

• ECCN Code:

  EAR99

• Date Of Intro:

  2018-09-28

• Manufacturer:

  Hamamatsu Photonics

• YTEOL:

  6

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Input Voltage-Max:

  5.25 V

• Input Voltage-Min:

  4.75 V

• Input Voltage-Nom:

  5 V

• JESD-30 Code:

  S-XQCC-N20

• Length:

  11.5 mm

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  20

• Operating Temperature-Max:

  60 °C

• Operating Temperature-Min:

  -20 °C

• Output Current-Max:

  0.002 A

• Output Voltage-Max:

  90 V

• Output Voltage-Min:

  20 V

• Output Voltage-Nom:

  60 V

• Package Body Material:

  UNSPECIFIED

• Package Code:

  QCCN

• Package Equivalence Code:

  LCC20,.4SQ

• Package Shape:

  SQUARE

• Package Style:

  CHIP CARRIER

• Peak Reflow Temperature (Cel):

  NOT SPECIFIED

• Ripple Voltage (Main Out):

  0.0000707 Vrms

• Seated Height-Max:

  2 mm

• Surface Mount:

  YES

• Technology:

  HYBRID

• Terminal Form:

  NO LEAD

• Terminal Pitch:

  1.5 mm

• Terminal Position:

  QUAD

• Time@Peak Reflow Temperature-Max (s):

  NOT SPECIFIED

• Total Power Output-Max:

  0.12 W

• Trim/Adjustable Output:

  YES

• Width:

  11.5 mm
