C14478-03 - Hamamatsu

C14478-03 Details

• Manufacturer Part Number:

  C14478-03

• Part Life Cycle Code:

  Active

• Package Description:

  MODULE-6

• ECCN Code:

  EAR99

• Manufacturer:

  Hamamatsu Photonics

• YTEOL:

  6

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Approvals:

  IEC

• Input Voltage-Max:

  5.25 V

• Input Voltage-Min:

  4.75 V

• JESD-30 Code:

  R-XDMA-P6

• Length:

  26 mm

• Line Regulation-Max:

  0.01%

• Load Regulation-Max:

  0.01%

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  6

• Operating Temperature-Max:

  60 °C

• Operating Temperature-Min:

  -10 °C

• Output Current-Max:

  1 A

• Output Voltage-Max:

  -250 V

• Output Voltage-Min:

  -10 V

• Package Body Material:

  UNSPECIFIED

• Package Code:

  DMA

• Package Equivalence Code:

  MODULE,6LEAD,.75

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Protections:

  OVER LOAD, REVERSE POLARITY , SHORT CIRCUIT

• Ripple Voltage (Main Out):

  0.00353 Vrms

• Screening Level:

  IEC 61010-1

• Seated Height-Max:

  8.5 mm

• Surface Mount:

  NO

• Technology:

  HYBRID

• Terminal Form:

  PIN/PEG

• Terminal Position:

  DUAL

• Total Power Output-Max:

  250 W

• Trim/Adjustable Output:

  NO

• Warm-up Time:

  0.04 s

• Width:

  17 mm
