C4550C508SV120RFSA1112.8MHZ - Vectron

C4550C508SV120RFSA1112.8MHZ Details

• Manufacturer Part Number:

  C4550C508SV120RFSA1112.8MHZ

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Transferred

• Package Description:

  ROHS COMPLIANT PACKAGE-5

• Manufacturer:

  Vectron International (now Microchip)

• Additional Feature:

  AT CUT CRYSTAL

• Aging:

  0.5 PPM/YEAR

• Control Voltage-Max:

  5 V

• Frequency Adjustment-Mechanical:

  NO

• Frequency Stability:

  0.05%

• Frequency Stability-Voltage:

  0.01 ppm

• Input Power:

  1 W

• JESD-609 Code:

  e1

• Mounting Feature:

  THROUGH HOLE MOUNT

• Number of Terminals:

  5

• Offset Frequency:

  1 kHz

• Operating Frequency-Nom:

  12.8 MHz

• Operating Temperature-Max:

  70 °C

• Oscillator Type:

  SINE

• Output Impedance:

  50 Ω

• Oven Supply Voltage:

  12V

• Phase Noise:

  -140 dBc/Hz

• Physical Dimension:

  25.4mm x 25.4mm x 11.25mm

• Supply Voltage-Max:

  12.6 V

• Supply Voltage-Min:

  11.4 V

• Supply Voltage-Nom:

  12 V

• Surface Mount:

  NO

• Terminal Finish:

  Tin/Silver/Copper (Sn/Ag/Cu)

• Warm-up Power:

  3 W

• Warm-up Time-Max:

  3 Minute
