C93404 - TE Connectivity

C93404 Details

• Manufacturer Part Number:

  C93404

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Transferred

• Package Description:

  ROHS COMPLIANT

• ECCN Code:

  EAR99

• HTS Code:

  8536.49.00.50

• Factory Lead Time:

  17 Weeks, 3 Days

• Manufacturer:

  TE Connectivity

• Additional Feature:

  RELEASE TIME WITH DIODE IN PARALLEL

• Body Breadth:

  10 mm

• Body Height:

  11 mm

• Body Length or Diameter:

  20.2 mm

• Coil Current(DC)-Max:

  0.003 A

• Coil Operate Voltage(DC):

  17.4 V

• Coil Power:

  150 mW

• Coil Release Voltage(DC):

  2.4 V

• Coil Resistance:

  15486 Ω

• Coil Voltage(DC)-Max:

  48 V

• Coil/Input Supply Type:

  DC

• Contact (AC) Max Rating R Load:

  1.25A@150VAC

• Contact Current(AC)-Max:

  1.25 A

• Contact Current(DC)-Max:

  1.25 A

• Contact (DC) Max Rating R Load:

  1.25A@150VDC

• Contact Voltage(AC)-Max:

  150 V

• Contact Voltage(DC)-Max:

  150 V

• Contact/Output Supply Type:

  AC/DC

• Electrical Life:

  200000 Cycle(s)

• Insertion Loss-Max:

  -0.97 dB

• Isolation-Max:

  -14.2 dB

• Mounting Feature:

  THROUGH HOLE-STRAIGHT

• Operate Time:

  10 ms

• Operating Frequency-Max:

  900 MHz

• Operating Frequency-Min:

  100 MHz

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -55 °C

• Packing Method:

  BOX; TUBE

• Physical Dimension:

  20.2mm X 10mm X 11mm

• Reference Standard:

  CECC; CSA; UL

• Relay Action:

  MOMENTARY

• Relay Function:

  DPDT

• Relay Type:

  RF RELAY

• Release Time:

  11 ms

• Sealing:

  IP67

• Surface Mount:

  NO

• Switching Time:

  21 ms

• Termination Type:

  SOLDER

• VSWR:

  1.31
