CA-IS3105W - ChipAnalog

CA-IS3105W Details

• Manufacturer Part Number:

  CA-IS3105W

• Part Life Cycle Code:

  Contact Manufacturer

• Package Description:

  SOIC-16

• ECCN Code:

  EAR99

• Manufacturer:

  ChipAnalog

• Additional Feature:

  ADDITIONAL 3.7V, 5V, 5.4V ALSO AVAILABLE

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Approvals:

  CSA; EN; IEC

• Efficiency (Main Output):

  55%

• Input Voltage-Max:

  5.5 V

• Input Voltage-Min:

  4.5 V

• Input Voltage-Nom:

  5 V

• JESD-30 Code:

  R-XDMA-G16

• Length:

  10.3 mm

• Line Regulation-Max:

  0.1515%

• Load Regulation-Max:

  2%

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  16

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  0.13 A

• Output Voltage-Max:

  3.53 V

• Output Voltage-Min:

  3.07 V

• Output Voltage-Nom:

  3.3 V

• Package Body Material:

  UNSPECIFIED

• Package Code:

  DMA

• Package Equivalence Code:

  MODULE,16LEAD,.4

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Protections:

  OVER CURRENT; OVER LOAD; SHORT CIRCUIT

• Ripple Voltage (Main Out):

  0.03535 Vrms

• Screening Level:

  EN 61010-1; IEC 60601

• Seated Height-Max:

  2.65 mm

• Surface Mount:

  YES

• Technology:

  HYBRID

• Terminal Form:

  GULL WING

• Terminal Pitch:

  1.27 mm

• Terminal Position:

  DUAL

• Total Power Output-Max:

  0.65 W

• Trim/Adjustable Output:

  NO

• Width:

  7.5 mm
