The recommended operating voltage range for the CA3083MZ96 is 4.5V to 15.5V, although it can operate up to 18V with reduced performance.
To ensure stability, it's essential to follow proper layout and grounding techniques, use a bypass capacitor between the supply pins, and avoid capacitive loads. Additionally, the datasheet recommends a minimum gain of 5 for stable operation.
The maximum power dissipation for the CA3083MZ96 is 500mW, and it's essential to ensure that the device does not exceed this limit to prevent overheating and damage.
While the CA3083MZ96 is an op-amp, it can be used as a comparator in certain applications. However, it's essential to note that the device is not optimized for comparator operation and may not provide the same level of performance as a dedicated comparator.
The CA3083MZ96 has built-in ESD protection, but it's still essential to follow proper handling and storage procedures to prevent damage. This includes using anti-static wrist straps, mats, and bags, and avoiding direct contact with the device pins.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
CA3083MZ96 Overview
Use the download button to access the CA3083MZ96 schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like CA308,
or try a keyword search, such as RF Small Signal Bipolar Transistors
