CAT28C16AG-20 - onsemi

CAT28C16AG-20 Details

• Manufacturer Part Number:

  CAT28C16AG-20

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  QFJ

• Package Description:

  QCCJ, LDCC32,.5X.6

• Pin Count:

  32

• Reach Compliance Code:

  Unknown

• Manufacturer:

  onsemi

• YTEOL:

  0

• Access Time-Max:

  200 ns

• Command User Interface:

  NO

• Data Polling:

  YES

• Endurance:

  10000 Write/Erase Cycles

• JESD-30 Code:

  R-PQCC-J32

• Length:

  13.97 mm

• Memory Density:

  16384 bit

• Memory IC Type:

  EEPROM

• Memory Width:

  8

• Moisture Sensitivity Level:

  1

• Number of Functions:

  1

• Number of Terminals:

  32

• Number of Words:

  2048 words

• Number of Words Code:

  2000

• Operating Mode:

  ASYNCHRONOUS

• Operating Temperature-Max:

  70 °C

• Organization:

  2KX8

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  QCCJ

• Package Equivalence Code:

  LDCC32,.5X.6

• Package Shape:

  RECTANGULAR

• Package Style:

  CHIP CARRIER

• Parallel/Serial:

  PARALLEL

• Peak Reflow Temperature (Cel):

  260

• Power Supplies:

  5 V

• Programming Voltage:

  5 V

• Qualification Status:

  Not Qualified

• Seated Height-Max:

  3.55 mm

• Standby Current-Max:

  0.0001 A

• Subcategory:

  EEPROMs

• Supply Current-Max:

  0.035 mA

• Supply Voltage-Max (Vsup):

  5.5 V

• Supply Voltage-Min (Vsup):

  4.5 V

• Supply Voltage-Nom (Vsup):

  5 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Temperature Grade:

  COMMERCIAL

• Terminal Form:

  J BEND

• Terminal Pitch:

  1.27 mm

• Terminal Position:

  QUAD

• Time@Peak Reflow Temperature-Max (s):

  30

• Toggle Bit:

  NO

• Width:

  11.43 mm

• Write Cycle Time-Max (tWC):

  10 ms
