CBM100S240 Frequently Asked Questions (FAQs)

• What is the recommended PCB layout and thermal design for optimal performance?
  Cincon recommends a 2-layer PCB with a solid ground plane on the bottom layer and a thermal pad on the top layer connected to the heat sink. A minimum of 2 oz copper thickness is recommended for the PCB. Additionally, a thermal interface material (TIM) with a thermal conductivity of 1 W/m-K or higher is recommended between the module and the heat sink.
• How do I ensure the module is properly cooled?
  The CBM100S240 requires a heat sink with a thermal resistance of 1.5°C/W or lower. Ensure good thermal contact between the module and the heat sink using a thermal interface material (TIM). The heat sink should be designed to dissipate 20W of power or more. Additionally, ensure good airflow around the heat sink to prevent overheating.
• What is the maximum allowed voltage deviation on the input pins?
  The input voltage deviation should be within ±10% of the nominal input voltage (100V) to ensure reliable operation. Exceeding this deviation may affect the module's performance, efficiency, or even cause damage.
• Can I use the CBM100S240 in a high-humidity environment?
  The CBM100S240 is designed to operate in a relative humidity (RH) of 60% or less. Operating the module in high-humidity environments (above 60% RH) may lead to reduced reliability or even failure. If high humidity is unavoidable, consider using conformal coating or other environmental protection measures.
• What is the recommended input capacitor value and type for the CBM100S240?
  Cincon recommends using a low-ESR ceramic capacitor with a value of 10uF to 22uF, rated for 250V or higher, as close to the input pins as possible. This helps to filter input noise and ensure stable operation.
