CBM150S240 - Cincon

CBM150S240 Details

• Manufacturer Part Number:

  CBM150S240

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  PACKAGE

• ECCN Code:

  EAR99

• Manufacturer:

  Cincon Electronics Corporation

• YTEOL:

  7

• Additional Feature:

  120-370 VDC ADDITIONAL INPUT IS AVAILABLE

• Analog IC - Other Type:

  AC-DC POWER FACTOR CORRECTION MODULE

• Approvals:

  IEC, EN, UL

• Efficiency (Main Output):

  92%

• Input Voltage-Max:

  264 V

• Input Voltage-Min:

  90 V

• Input Voltage-Nom:

  100 V

• JESD-30 Code:

  R-XXMA-X

• Length:

  116.8 mm

• Line Regulation-Max:

  0.5%

• Load Regulation-Max:

  1%

• Number of Functions:

  1

• Number of Outputs:

  1

• Operating Temperature-Max:

  90 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  6.25 A

• Output Voltage-Max:

  25.2 V

• Output Voltage-Min:

  22.8 V

• Output Voltage-Nom:

  24 V

• Package Body Material:

  UNSPECIFIED

• Package Code:

  XMA

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Protections:

  OVER CURRENT, OVER VOLTAGE, UNDER VOLTAGE, SHORT CIRCUI, OVER TEMP

• Ripple Voltage (Main Out):

  0.08484 Vrms

• Screening Level:

  IEC/EN/UL 62368-1

• Seated Height-Max:

  20.2 mm

• Surface Mount:

  NO

• Technology:

  HYBRID

• Terminal Form:

  UNSPECIFIED

• Terminal Position:

  UNSPECIFIED

• Total Power Output-Max:

  150 W

• Trim/Adjustable Output:

  YES

• Width:

  61 mm
