CD4007UBPWE4 - Rochester Electronics

CD4007UBPWE4 Details

• Manufacturer Part Number:

  CD4007UBPWE4

• Part Life Cycle Code:

  Contact Manufacturer

• Package Description:

  GREEN, PLASTIC, TSSOP-14

• HTS Code:

  8542.39.00.60

• Manufacturer:

  Rochester Electronics LLC

• Additional Feature:

  DUAL COMPLEMENTARY PAIR PLUS INVERTER

• Family:

  4000/14000/40000

• JESD-30 Code:

  R-PDSO-G14

• Length:

  5 mm

• Logic IC Type:

  INVERTER

• Number of Functions:

  3

• Number of Inputs:

  1

• Number of Terminals:

  14

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -55 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  TSSOP

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE, THIN PROFILE, SHRINK PITCH

• Propagation Delay (tpd):

  110 ns

• Seated Height-Max:

  1.2 mm

• Supply Voltage-Max (Vsup):

  18 V

• Supply Voltage-Min (Vsup):

  3 V

• Supply Voltage-Nom (Vsup):

  5 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Temperature Grade:

  MILITARY

• Terminal Form:

  GULL WING

• Terminal Pitch:

  0.65 mm

• Terminal Position:

  DUAL

• Width:

  4.4 mm
