CF-CA-1CB4-P412 - Nidec Copal

CF-CA-1CB4-P412 Details

• Manufacturer Part Number:

  CF-CA-1CB4-P412

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.50.90.40

• Manufacturer:

  Nidec Copal Electronics Corporation

• YTEOL:

  7

• Actuator Type:

  BUTTON TYPE

• Body Breadth:

  3.8 mm

• Body Height:

  7 mm

• Body Length or Diameter:

  6.7 mm

• Circuit Configuration:

  1X1

• Contact Current(DC)-Max:

  0.05 A

• Contact (DC) Max Rating R Load:

  .05A@32VDC

• Contact Voltage(DC)-Max:

  32 V

• Electrical Life:

  100000 Cycle(s)

• JESD-609 Code:

  e4

• Mounting Feature:

  SURFACE MOUNT-RIGHT ANGLE

• Number of Switches:

  1

• Operating Force-Max:

  4.5 N

• Operating Temperature-Max:

  90 °C

• Operating Temperature-Min:

  -40 °C

• Packing Method:

  BAG

• Surface Mount:

  NO

• Switch Action:

  MOMENTARY

• Switch Function:

  SPST

• Switch Type:

  KEYPAD SWITCH

• Terminal Finish:

  Gold (Au)

• Termination Type:

  SOLDER
