Cosel recommends a PCB layout with a large copper area connected to the module's thermal pad to ensure efficient heat dissipation. A minimum of 2 oz copper thickness is recommended, and the copper area should be connected to a solid ground plane to reduce thermal resistance.
Yes, the CHS1202424-B is designed to withstand high-vibration environments. However, it's essential to ensure that the module is properly secured to the PCB and that the PCB is rigid enough to prevent flexing or cracking. Additionally, the module's thermal interface material should be suitable for high-vibration applications.
To ensure reliable start-up and shutdown, it's recommended to follow a soft-start and soft-shutdown sequence. This can be achieved by gradually ramping up the input voltage and current during start-up, and gradually reducing them during shutdown. This helps to prevent inrush currents and reduces stress on the module.
The recommended input fuse rating for the CHS1202424-B is 5A to 10A, depending on the specific application and input voltage. It's essential to choose a fuse that can handle the maximum input current and provide adequate protection against overcurrent conditions.
Yes, the CHS1202424-B can be used in a redundant or parallel configuration to achieve higher power ratings or to provide redundancy in critical applications. However, it's essential to ensure that the modules are properly synchronized and that the system is designed to handle the increased power and heat dissipation.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
CHS1202424-B Overview
Use the download button to access the CHS1202424-B schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like CHS12,
or try a keyword search, such as Power Supply Modules
