CHS3002405-BC - Cosel

CHS3002405-BC Details

• Manufacturer Part Number:

  CHS3002405-BC

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  DMA,

• Reach Compliance Code:

  Unknown

• ECCN Code:

  EAR99

• Date Of Intro:

  2017-02-17

• Manufacturer:

  Cosel USA Inc

• YTEOL:

  7

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Input Voltage-Max:

  36 V

• Input Voltage-Min:

  18 V

• Input Voltage-Nom:

  24 V

• JESD-30 Code:

  R-XDMA-P8

• Length:

  61.1 mm

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  8

• Output Voltage-Max:

  6 V

• Output Voltage-Min:

  4 V

• Output Voltage-Nom:

  5 V

• Package Body Material:

  UNSPECIFIED

• Package Code:

  DMA

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Peak Reflow Temperature (Cel):

  260

• Seated Height-Max:

  14.8 mm

• Surface Mount:

  NO

• Technology:

  HYBRID

• Terminal Form:

  PIN/PEG

• Terminal Position:

  DUAL

• Time@Peak Reflow Temperature-Max (s):

  15

• Total Power Output-Max:

  200 W

• Trim/Adjustable Output:

  YES

• Width:

  26.1 mm
