CK1049 Details

• Manufacturer Part Number:

  CK1049

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Contact Manufacturer

• Package Description:

  ROHS COMPLIANT

• Country Of Origin:

  UK

• ECCN Code:

  EAR99

• HTS Code:

  8536.50.90.20

• Manufacturer:

  Lorlin Electronics LTD

• Actuator Type:

  SPINDLE

• Body Height:

  14.1 mm

• Body Length or Diameter:

  26.2 mm

• Contact (AC) Max Rating R Load:

  .15A@250VAC

• Contact Current(AC)-Max:

  0.15 A

• Contact Current(DC)-Max:

  0.15 A

• Contact (DC) Max Rating R Load:

  .15A@250VDC

• Contact Voltage(AC)-Max:

  250 V

• Contact Voltage(DC)-Max:

  250 V

• Electrical Life:

  10000 Cycle(s)

• Indexing Angle:

  30 deg

• JESD-609 Code:

  e4

• Mounting Feature:

  THROUGH HOLE-STRAIGHT

• Number of Positions:

  12

• Number of Switch Sections:

  1

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -30 °C

• Surface Mount:

  NO

• Switch Action:

  LATCHED

• Switch Function:

  SP12T

• Switch Type:

  ROTARY SWITCH

• Terminal Finish:

  SILVER

• Termination Type:

  SOLDER
