CL-GD5434-QC-A - Cirrus Logic

CL-GD5434-QC-A Details

• Manufacturer Part Number:

  CL-GD5434-QC-A

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  QFP

• Package Description:

  PLASTIC, QFP-208

• Pin Count:

  208

• ECCN Code:

  3A001.a.3

• HTS Code:

  8542.31.00.30

• Manufacturer:

  Cirrus Logic

• YTEOL:

  0

• Address Bus Width:

  32

• Bit Size:

  64

• Bus Compatibility:

  PCI; VL; ISA; 80486

• Clock Frequency-Max:

  50 MHz

• Display Configuration:

  1280 X 1024 PIXELS

• External Data Bus Width:

  32

• JESD-30 Code:

  S-PQFP-G208

• JESD-609 Code:

  e0

• Length:

  28 mm

• Number of Terminals:

  208

• Operating Temperature-Max:

  70 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  FQFP

• Package Equivalence Code:

  QFP208,1.2SQ,20

• Package Shape:

  SQUARE

• Package Style:

  FLATPACK, FINE PITCH

• Qualification Status:

  Not Qualified

• Seated Height-Max:

  4.07 mm

• Supply Current-Max:

  296 mA

• Supply Voltage-Max:

  5.25 V

• Supply Voltage-Min:

  4.75 V

• Supply Voltage-Nom:

  5 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Temperature Grade:

  COMMERCIAL

• Terminal Finish:

  Tin/Lead (Sn/Pb)

• Terminal Form:

  GULL WING

• Terminal Pitch:

  0.5 mm

• Terminal Position:

  QUAD

• Width:

  28 mm

• uPs/uCs/Peripheral ICs Type:

  DISPLAY CONTROLLER, CRT GRAPHICS DISPLAY
