API Delevan recommends a 4-layer PCB with a solid ground plane, and thermal vias under the device to dissipate heat. A thermal pad on the bottom of the device should be connected to a large copper area on the PCB to improve heat dissipation.
The CM6460R-504 requires a bias voltage of 5V ± 0.5V, and a bias current of 100mA ± 10%. Ensure the bias circuitry is designed to provide a stable voltage and current to the device.
The CM6460R-504 is designed to operate from 6 GHz to 18 GHz, with optimal performance between 8 GHz and 12 GHz. Operating outside this range may affect device performance and reliability.
API Delevan recommends using ESD protection devices, such as TVS diodes, on the input and output lines to protect the CM6460R-504 from electrostatic discharge. A minimum of 2kV HBM and 100V MM protection is recommended.
The CM6460R-504 has a typical power consumption of 1.5W, with a maximum rating of 2.5W. Ensure the power supply can provide a stable voltage and current to the device.
Trust Checks
This model has been verified by system checks.
System Verified
Sponsored
CM6460R-504 Overview
Use the download button to access the CM6460R-504 schematic symbol and PCB footprint.
To find more CAD model downloads similar to this part, try a partial part number search, like CM646,
or try a keyword search, such as Data Line Filters
