CMA-81+ - Mini-Circuits

CMA-81+ Details

• Manufacturer Part Number:

  CMA-81+

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• Manufacturer:

  Mini-Circuits

• YTEOL:

  6

• Characteristic Impedance:

  50 Ω

• Construction:

  COMPONENT

• Gain:

  8 dB

• Input Power-Max (CW):

  13 dBm

• JESD-609 Code:

  e4

• Mounting Feature:

  SURFACE MOUNT

• Number of Functions:

  1

• Number of Terminals:

  8

• Operating Frequency-Max:

  6000 MHz

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  CERAMIC, METAL-SEALED COFIRED

• Power Supplies:

  5 V

• RF/Microwave Device Type:

  WIDE BAND LOW POWER

• Supply Current-Max:

  112 mA

• Surface Mount:

  YES

• Technology:

  HBT

• Terminal Finish:

  Nickel/Palladium/Gold (Ni/Pd/Au)

• VSWR-Max:

  1.2
