CMA7N14Y1 - Bernier

CMA7N14Y1 Details

• Manufacturer Part Number:

  CMA7N14Y1

• Part Life Cycle Code:

  Contact Manufacturer

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.10

• Manufacturer:

  Bernier Relais et Connecteurs

• Additional Feature:

  EMI-RFI SHIELDED

• Body Depth:

  0.988 inch

• Body Diameter:

  0.807 inch

• Body/Shell Style:

  RECEPTACLE

• Configuration:

  1X1 VERTICAL

• Connector Type:

  GENERAL PURPOSE AUDIO

• Contact Gender:

  FEMALE

• Contact Resistance:

  10 mΩ

• Contact Style:

  RND PIN-SKT

• DIN Conformance:

  NO

• Dielectric Withstanding Voltage:

  500VAC V

• Durability:

  10000 Cycles

• IEC Conformance:

  NO

• Insulation Resistance:

  1000000000 Ω

• Insulator Material:

  THERMOSET

• MIL Conformance:

  NO

• Mounting Option 1:

  LOCKING

• Mounting Type:

  BOARD AND PANEL

• Number of Poles:

  14

• Number of Ports:

  1

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -55 °C

• Option:

  WATERPROOF

• Polarization Key:

  POLARIZED HOUSING

• Rated Current (Signal):

  1.5 A

• Shell Material:

  STAINLESS STEEL

• Terminal Length:

  0.157 inch

• Termination Type:

  SOLDER
