CPC1561BTR - LITTELFUSE

CPC1561BTR Details

• Manufacturer Part Number:

  CPC1561BTR

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• HTS Code:

  8541.40.95.00

• Manufacturer:

  Littelfuse Inc

• YTEOL:

  5.59

• Additional Feature:

  UL RECOGNIZED

• Configuration:

  COMPLEX

• Control Current:

  0.00065 A

• Control Voltage:

  0.9 V

• Forward Current-Max:

  0.0025 A

• Input Type:

  DC

• Isolation Voltage-Max:

  3750 V

• Mounting Feature:

  SURFACE MOUNT

• Number of Elements:

  1

• On-State Current-Max:

  1 A

• On-state Resistance-Max:

  0.245 Ω

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Optoelectronic Device Type:

  TRANSISTOR OUTPUT SSR

• Output Circuit Type:

  MOSFET

• Overall Height:

  2.337 mm

• Overall Length:

  10.211 mm

• Packing Method:

  TR, EMBOSSED, 13 INCH

• Surface Mount:

  YES

• Terminal Finish:

  TIN
