CQHS2504832 - Cosel

CQHS2504832 Details

• Manufacturer Part Number:

  CQHS2504832

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Not Recommended

• Package Description:

  ROHS COMPLIANT, DIP-8

• ECCN Code:

  EAR99

• Manufacturer:

  Cosel USA Inc

• YTEOL:

  3

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Approvals:

  C-UL-US, CE, CUL, CSA, EN, UKCA, UL

• Efficiency (Main Output):

  94%

• Input Voltage-Max:

  76 V

• Input Voltage-Min:

  36 V

• Input Voltage-Nom:

  48 V

• JESD-30 Code:

  R-PDIP-P8

• Length:

  57.9 mm

• Line Regulation-Max:

  0.2%

• Load Regulation-Max:

  0.2%

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  8

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  7.9 A

• Output Voltage-Max:

  35.2 V

• Output Voltage-Min:

  26.88 V

• Output Voltage-Nom:

  32 V

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  DIP

• Package Equivalence Code:

  DIP8,2(UNSPEC)

• Package Shape:

  RECTANGULAR

• Package Style:

  IN-LINE

• Peak Reflow Temperature (Cel):

  260

• Protections:

  OVER CURRENT, OVER VOLTAGE

• Ripple Voltage (Main Out):

  0.144935 Vrms

• Screening Level:

  EN 62368-1

• Seated Height-Max:

  10.5 mm

• Surface Mount:

  NO

• Technology:

  HYBRID

• Terminal Form:

  PIN/PEG

• Terminal Position:

  DUAL

• Time@Peak Reflow Temperature-Max (s):

  15

• Total Power Output-Max:

  252.8 W

• Trim/Adjustable Output:

  YES

• Warm-up Time:

  0.2 s

• Width:

  22.76 mm
