CS-4-22YB - Nidec Copal

CS-4-22YB Details

• Manufacturer Part Number:

  CS-4-22YB

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.50.70.00

• Factory Lead Time:

  15 Weeks

• Manufacturer:

  Nidec Copal Electronics Corporation

• Actuator Type:

  ROTARY SCREW

• Body Breadth:

  4.4958 mm

• Body Height:

  2.286 mm

• Body Length or Diameter:

  5.0038 mm

• Contact Resistance:

  0.1 mΩ

• Dielectric Withstand Volts:

  500VAC V

• End Contact Material:

  COPPER ALLOY

• End Contact Plating:

  GOLD

• Insulation Resistance:

  100000000 Ω

• JESD-609 Code:

  e4

• Mounting Feature:

  SURFACE MOUNT-STRAIGHT

• Number of Positions:

  2

• Operating Temperature-Max:

  70 °C

• Operating Temperature-Min:

  -25 °C

• Surface Mount:

  NO

• Switch Action:

  CIRCULAR

• Switch Type:

  ROTARY SWITCH

• Terminal Finish:

  Gold (Au)

• Terminal Material:

  COPPER ALLOY

• Termination Type:

  SOLDER
