CS20-25moT1 - LITTELFUSE

CS20-25moT1 Details

• Manufacturer Part Number:

  CS20-25MOT1

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8541.30.00.80

• Manufacturer:

  Littelfuse Inc

• YTEOL:

  7.43

• Case Connection:

  ANODE

• Configuration:

  SINGLE

• DC Gate Trigger Current-Max:

  250 mA

• JEDEC-95 Code:

  TO-268AA

• JESD-30 Code:

  R-PSSO-G2

• JESD-609 Code:

  e3

• Number of Elements:

  1

• Number of Terminals:

  2

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Peak Reflow Temperature (Cel):

  NOT SPECIFIED

• Qualification Status:

  Not Qualified

• RMS On-state Current-Max:

  30 A

• Repetitive Peak Off-state Voltage:

  2500 V

• Repetitive Peak Reverse Voltage:

  2500 V

• Surface Mount:

  YES

• Terminal Finish:

  PURE TIN

• Terminal Form:

  GULL WING

• Terminal Position:

  SINGLE

• Time@Peak Reflow Temperature-Max (s):

  NOT SPECIFIED

• Trigger Device Type:

  SCR
